Edge-to-edge cooktop
Extra-large integrated griddle
15,000 BTU Power Boil Burner
Dimensions: 47.25 H x 30 W x 28.75 D

ACCESSORIES
- Center GrateOptional - JXGRATE1
- Griddle AccessoryIntegrated Griddle (Included)
- LP Conversion KitIncluded
APPEARANCE
- Color AppearanceStainless Steel/Black
- Control KnobsStainless Steel Appearance
- Cooktop Burner Grate ColorMatte Black
- HandleDesigner Style
- Handle ColorStainless Steel
- Oven Door FeaturesBig View Oven Window
CAPACITY
- Total Capacity (cubic feet)5.00 cu ft
FEATURES
- Burner - Center10,000 BTU Oval
- Burner - Left Front15,000 BTU
- Burner - Left Rear5,000 BTU Precise Simmer
- Burner - Right Front9,500 BTU
- Burner - Right Rear12,000 BTU
- ConfigurationRange with Broiler Drawer
- Control LocationFront
- Control TypeElectronic Touch
- Cooking TechnologyTraditional
- Cooktop Burner Grate FeaturesContinuous Grates
- Cooktop Burner Grate MaterialHeavy Cast Iron
- Cooktop Burner TypeSealed
- Cooktop SurfaceEdge-to-Edge
  One-Piece Upswept
  Porcelain-Enamel
  Black
- Cooktop TypeContinuous Grates with Griddle
- Drawer TypeBroiler
- Fuel TypeNatural Gas
- GriddleIntegrated (Included)
- Ignition SystemElectronic
- Interior Oven Light1 Incandescent
- OU CertifiedEmbedded OU/CRC Enhanced Shabbos Mode
- Oven Cleaning TypeSteam Clean
- Oven Control FeaturesAudible Preheat Signal
  Auto Oven Shut-Off
  Delay Bake Option
  Electronic Clock and Timer
  Hi / Low Broil
  Oven Control Lock Capability
- Oven Rack Features2 Flat Nickel Racks
- Oven Rack Positions (Single or Upper/Lower)6
- Product TypeFree-Standing Single Oven
- Sabbath ModeYes
POWER / RATINGS
- Bake/Broiler BTU Rating - LP (000's BTU's)16.0 Bake / 16.0 Broiler
- Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)18.0 Bake / 18.0 Broiler
- Top Burner BTU Rating - LP (000's BTU's)(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 8.0
- Top Burner BTU Rating - Nat. Gas (000's BTU's)(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 10.0
- Volts/Hertz/Amps120v; 60Hz; 15A
WARRANTY
- Labor WarrantyLimited 1-year entire appliance
- Parts WarrantyLimited 1-year entire appliance
- Warranty NotesSee written warranty for full details
WEIGHTS & DIMENSIONS
- Approximate Shipping Weight172 lb
- Cabinet Width30 in
- Depth with Door Open46.25 in
- Depth Without Handle26.25 in
- Height to Cooking Surface (in.)36 - 36.5
- Net Weight150 lb
- Oven Interior Dimensions (W x H x D) (in.)24 x 19 x 19
- Overall Depth28.75 in
- Overall Height47.25 in
- Overall Width30 in
